New Holland TS100
|
|
| Production | |
| Manufacturer | New Holland |
| Built in Basildon, England | |
| New Holland TS100 Engine | |
| New Holland 5.0L 4-cyl diesel | |
| Fuel tank | 42 gal 159.0 L |
 Engine details ... | |
| New Holland TS100 Transmissions | |
| 8-speed unsynchronized gear | |
| 16-speed two-speed power shift | |
| 12-speed | |
| 24-speed | |
| 16-speed | |
 Transmission details ... |
| New Holland TS100 Power | |
| Engine | 100 hp 74.6 kW |
| PTO (claimed) | 80 hp 59.7 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Power steering | |
| Hydraulic wet disc brakes | |
| Two-post folding ROPS. Cab optional with air-conditioning. |
| Photos | |
 | |
 New Holland TS100 photos... | |
| Hydraulics | |
| Type | open center |
| closed center OptOptional | |
| Pressure | 2500 psi 172.4 bar |
| 2700 psi*Open center 186.2 bar | |
| Valves | 2 to 4 |
| Pump flow | 9.7 gpm 36.7 lpm |
| 18.2 gpm*Optional pump 68.9 lpm | |
| 21 gpm*Closed center 79.5 lpm | |
| Total flow | 37 gpm 140.0 lpm |
| Steering flow | 9.5 gpm 36.0 lpm |
| Steering press. | 2100 psi (2WD) 144.8 bar |
| 2500 psi (4WD) 172.4 bar | |
| Tractor hitch | |
| Rear Type | II,IIN |
| Rear lift (at 24"/610mm) | 4,200 lbs 1905 kg |
| 6,210 lbs (assist ram) 2816 kg | |
| 8,240 lbs (two assist rams) 3737 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| Dimensions & Tires | |
| 2WD Wheelbase | 92.1 inches 233 cm |
| 4WD Wheelbase | 93 inches 236 cm |
| Weight | 7275 to 9855 pounds |
| Front tire | 7.50-16 |
| Rear tire | 16.9-30 |
 Full dimensions and tires ... | |
| TS100 Serial Numbers | |
| Location: | Serial number decal inside the hood on the right side of the tractor. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 55 |
| 100 (cab) | |
| Batteries | 1 |
| 2 *Second battery optional with cabin. | |
| Battery CCA | 800 |
| Battery volts | 12 |
| References | |
 | |
| Operator's Manual TS90 - TS100 - TS110: EconoShift (86562958) published in 1998 | |
| Operator's Manual TS90 - TS100 - TS110: Synchro Command and ElectroShift (86562959) published in 1998 | |
| TS90 TS100 TS110 TS115 Operator's Manual (86630281) published in 2001 | |
| North American Buyer's Guide published in 1997, by New Holland |
