Tractors > New Holland > TS90

New Holland TS90



New Holland TS90 tractor photo
1999 - 2003
TS Series
Series map:
TS90
TS100
90.0hp
100.0hp
Production
ManufacturerNew Holland
Built in Basildon, England
New Holland TS90 Engine
5.0L 4-cyl diesel
Fuel tank42 gal
159.0 L
Engine details ...
New Holland TS90 Transmissions
8-speed unsynchronized gear
16-speed two-speed power shift
12-speed
24-speed
16-speed
Transmission details ...
New Holland TS90 Power
Engine90 hp
67.1 kW
PTO (claimed)70 hp
52.2 kW
Mechanical
Two- or four-wheel drive
Power steering
Hydraulic wet disc brakes
Two-post folding ROPS. Cab optional with air-conditioning.
Photos
No photos of the New Holland TS90 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
 closed center OptOptional
Pressure2500 psi
172.4 bar
 2700 psi (open center)
186.2 bar
Valves2 to 4
Pump flow9.7 gpm
36.7 lpm
 18.2 gpm (optional pump)
68.9 lpm
 21 gpm (closed center)
79.5 lpm
Steering flow9.5 gpm
36.0 lpm
Steering press.2100 psi (2WD)
144.8 bar
 2500 psi (4WD)
172.4 bar
Tractor hitch
Rear TypeII
Rear lift (at 24"/610mm)4,200 lbs
1905 kg
 6,210 lbs (assist ram)
2816 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
Dimensions & Tires
2WD Wheelbase92.1 inches
233 cm
4WD Wheelbase93 inches
236 cm
Weight7275 to 9722 pounds
Front tire7.50-16
Rear tire16.9-30
Full dimensions and tires ...
TS90 Serial Numbers
Location:Serial number decal inside the hood on the right side of the tractor.
Electrical
Groundnegative
Charging systemalternator
Charging amps55
 100 (cab)
Batteries1
 2 *Second battery optional with cabin.
Battery CCA800
Battery volts12
References
TS90 references literature
Operator's Manual TS90 - TS100 - TS110: EconoShift (86562958) published in 1998
Operator's Manual TS90 - TS100 - TS110: Synchro Command and ElectroShift (86562959) published in 1998
TS90 TS100 TS110 TS115 Operator's Manual (86630281) published in 2001
North American Buyer's Guide published in 1997, by New Holland
