Lawn Tractors > Simplicity > Broadmoor 18H

Simplicity Broadmoor 18H



Simplicity Broadmoor 18H lawn tractor photo
1997 - 2004
Model year
Broadmoor Series
Lawn tractor
Series map:
Broadmoor 16VH
Broadmoor 18H
16.0hp
18.0hp
Production
ManufacturerSimplicity
Lawn tractor
Variants
2618Hsimilar Massey Ferguson model
Simplicity Broadmoor 18H Engine
18HP Vanguard 622cc 2-cyl gasoline
Fuel tank4 gal
15.1 L
Engine details ...
Simplicity Broadmoor 18H Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
Simplicity Broadmoor 18H
Simplicity Broadmoor 18H photos...
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase50.75 inches
128 cm
Weight424 lbs
192 kg
Front tire15x6.0-6
Rear tire20x8.0-8
Full dimensions and tires ...
Simplicity Broadmoor 18H attachments
50" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Battery volts12
References
Broadmoor 18H references literature
Operator's Manual Broadmoor published in 1998
Operator's Manual Broadmoor published in 2001
Service & Repair Manual Broadmoor Series (TP 500-2493-00-BM-SMA) published in 2001
