AGCO 1618H
|
|
Note: the AGCO model 1618H is the same as the Simplicity Broadmoor 18H. The following data is from the Broadmoor 18H listing. |
| Production | |
| Distributor | AGCO |
| Manufacturer | Simplicity |
| Lawn tractor | |
| AGCO 1618H Engine | |
| 18HP Vanguard 569cc 2-cyl gasoline | |
| Fuel tank | 4 gal 15.1 L |
 Engine details ... | |
| AGCO 1618H Transmission | |
| hydrostatic | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Open operator station. |
| Photos | |
| No photos of the AGCO 1618H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | electric |
| Mid PTO Type | pulley |
| Dimensions & Tires | |
| Wheelbase | 50.75 inches 128 cm |
| Weight | 424 lbs 192 kg |
| Front tire | 15x6.0-6 |
| Rear tire | 20x8.0-8 |
 Full dimensions and tires ... | |
| AGCO 1618H attachments | |
| 50" mid-mount mower deck | |
| snowblower | |
| blade | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Lawn and Garden Equipment published in 2000, by AGCO | |
| Product Guide Fall 1998 published by Simplicity |
