Tractors > CaseIH > Farmall 90C

CaseIH Farmall 90C



CaseIH Farmall 90C tractor photo
2015 - 2027
Model year
Farmall C Series
Utility tractor
Series map:
Farmall 90C
Farmall 100C
80.0hp*
93.3hp*
*Estimated engine power for comparison only.
Production
ManufacturerCaseIH (a part of CNH)
Utility tractor
Variants
PowerStar 90similar New Holland model
CaseIH Farmall 90C Engine
FPT 3.6L 4-cyl diesel
Fuel tank34.3 gal
129.8 L
Exhaust fluid (DEF)3.4 gal
12.9 L
Engine details ...
CaseIH Farmall 90C Transmission
24-speed two-speed power shift
Transmission details ...
CaseIH Farmall 90C Power
Engine (max)89 hp
66.4 kW
PTO (claimed)72 hp
53.7 kW
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic
Hydraulic wet disc brakes
Cab standard with air-conditioning.
Photos
No photos of the CaseIH Farmall 90C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Rear valves2 or 3
Pump flow21.7 gpm
82.1 lpm
Steering flow9.7 gpm
36.7 lpm
Tractor hitch
Rear TypeII
Controlposition and draft control
Rear lift (at 24"/610mm)4123 lbs
1870 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000
Engine RPM540@1935
 540E@1535
 1000@1926
Dimensions & Tires
Wheelbase92.5 inches
234 cm
Weight10240 lbs
4644 kg
Full dimensions and tires ...
CaseIH Farmall 90C attachments
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
Farmall 90C references literature
Farmall C published in 2025, by CaseIH
Farmall Utility C Specifications published in 2025, by CaseIH
