Tractors > New Holland > PowerStar 90

New Holland PowerStar 90



New Holland PowerStar 90 tractor photo
2018 - 2027
Model year
PowerStar Series
Utility tractor
Series map:
PowerStar 90
PowerStar 100
84.5hp*
86.7hp*
*Estimated engine power for comparison only.
Production
ManufacturerNew Holland (a part of CNH)
Utility tractor
Variants
Farmall 90Csimilar CaseIH model
New Holland PowerStar 90 Engine
FPT 3.6L 4-cyl diesel
ROPS Fuel tank30.3 gal
114.7 L
Cab Fuel tank34.3 gal
129.8 L
ROPS Exhaust fluid (DEF)2.8 gal
10.6 L
Cab Exhaust fluid (DEF)3.4 gal
12.9 L
Engine details ...
New Holland PowerStar 90 Transmission
24-speed two-speed power shift
Transmission details ...
New Holland PowerStar 90 Power
Engine (max)89 hp
66.4 kW
Mechanical
Two- or four-wheel drive
Differential lockelectro-hydraulic
Hydraulic wet disc brakes
Two-post folding ROPS. Cab optional with air-conditioning.
Photos
No photos of the New Holland PowerStar 90 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Rear valves2 or 3
ROPS Pump flow16.9 gpm
64.0 lpm
Cab Pump flow21.7 gpm
82.1 lpm
Steering flow9.7 gpm
36.7 lpm
Tractor hitch
Rear TypeII
Controlposition and draft control
Rear lift (at 24"/610mm)4123 lbs
1870 kg
 6938 lbsOptOptional
3147 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000
Dimensions & Tires
Wheelbase92.5 inches
234 cm
Weight8157 to 10240 pounds
Front tire12.4-24
2WD Rear tire18.4-30
Full dimensions and tires ...
New Holland PowerStar 90 attachments
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps120
Battery CCA800
Battery volts12
References
PowerStar 90 references literature
Powerstar Series Tractors published in 2025, by New Holland
