CaseIH Farmall 100C
|
|
Series map:
Farmall 90C
Farmall 100C
Farmall 110C
80.0hp*
93.3hp*
102.2hp*
*Estimated engine power for comparison only.
| Production | |
| Manufacturer | CaseIH (a part of CNH) |
| Utility tractor | |
| Variants | |
| PowerStar 100 | similar New Holland model |
| CaseIH Farmall 100C Engine | |
| FPT 3.6L 4-cyl diesel | |
| Fuel tank | 34.3 gal 129.8 L |
| Exhaust fluid (DEF) | 3.4 gal 12.9 L |
 Engine details ... | |
| CaseIH Farmall 100C Transmissions | |
| 24-speed two-speed power shift | |
| 12-speed power shuttle | |
| 24-speed creeper | |
 Transmission details ... |
| CaseIH Farmall 100C Power | |
| Engine (max) | 99 hp 73.8 kW |
| PTO (claimed) | 84 hp 62.6 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electro-hydraulic |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the CaseIH Farmall 100C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Rear valves | 2 or 3 |
| Pump flow | 21.7 gpm 82.1 lpm |
| Steering flow | 9.7 gpm 36.7 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift (at 24"/610mm) | 4123 lbs 1870 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Rear PTO Type | 540/1000 |
| Engine RPM | 540@1935 |
| 540E@1535 | |
| 1000@1926 | |
| Dimensions & Tires | |
| Wheelbase | 92.5 inches 234 cm |
| Weight | 10240 lbs 4644 kg |
 Full dimensions and tires ... | |
| CaseIH Farmall 100C attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| Farmall C published in 2025, by CaseIH | |
| Farmall Utility C Specifications published in 2025, by CaseIH |
