Massey Ferguson 5712S
|
|
| Production | |
| Manufacturer | Massey Ferguson (a part of AGCO) |
| Utility tractor | |
| Variants | |
| 5712M | basic |
| 5712S | deluxe |
| Massey Ferguson 5712S Engine | |
| AGCO Power 4.4L 4-cyl diesel | |
| Fuel tank | 47.6 gal 180.2 L |
| Exhaust fluid (DEF) | 6.6 gal 25.0 L |
 Engine details ... | |
| Massey Ferguson 5712S Transmissions | |
| 16-speed four-speed power shift | |
| 24-speed six-speed power shift | |
 Transmission details ... |
| Massey Ferguson 5712S Power | |
| Engine | 115 hp 85.8 kW |
| Engine (max) | 120 hp 89.5 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electro-hydraulic front and rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | pneumatic |
| hydraulic OptOptional | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the Massey Ferguson 5712S are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| closed center OptOptional | |
| Pressure | 2901 psi 200.0 bar |
| Valves | 2 to 4 |
| Pump flow | 15.3 gpm (open center) 57.9 lpm |
| 26.4 gpm (open center)OptOptional 99.9 lpm | |
| 29 gpm (closed center) 109.8 lpm | |
| Steering flow | 8.5 gpm 32.2 lpm |
| Tractor hitch | |
| Rear Type | III/II |
| Rear lift | 11464 lbs 5200 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@1920 |
| 540E@1560 | |
| 1000@1960 | |
| Dimensions & Tires | |
| Wheelbase | 100.4 inches 255 cm |
| Weight | 10582 lbs 4799 kg |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| MF 5700 S published in 2017, by Massey Ferguson | |
| 5700S Series published in 2020, by Massey Ferguson |
