Massey Ferguson 5712SL
| | 2016 - 2018 |
| 5700SL Series | | Utility tractor |
|
| Production |
| Manufacturer | Massey Ferguson (a part of AGCO)
|
| Utility tractor |
| Built in Beauvais, France |
| Original price was $100,073 in 2018 |
| Massey Ferguson 5712SL Power |
| Engine | 115 hp
85.8 kW
|
| PTO (claimed) | 95 hp
70.8 kW
|
| Mechanical |
| Two- or four-wheel drive |
| Final drives | planetary
|
| Differential lock | electro-hydraulic front and rear
|
| Power steering |
| Hydraulic wet disc brakes |
| Trailer brakes | hydraulic OptOptional
|
| | pneumatic OptOptional
|
| Cab standard with air-conditioning. Auto-Guide 3000 ((Optional)) |
| Photos |
| No photos of the Massey Ferguson 5712SL are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| | closed center load-sensing OptOptional
|
| Pressure | 2900 psi
200.0 bar
|
| Valves | 1 to 4
|
| Pump flow | 15 gpm
56.8 lpm
|
| | 26 gpm (Twin-Flow)
98.4 lpm
|
| | 29 gpm (CCLS)
109.8 lpm
|
| Tractor hitch |
| Rear Type | III/II
|
| Control | lower-link draft sensing
|
| Rear lift (at 24"/610mm) | 8575 lbs
3889 kg
|
| Drawbar | Cat. 2
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic
|
| Rear PTO Type | 540/540E (1.375)
|
| | 540/540E/1000 (1.375)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Classic Charging amps | 120
|
| Deluxe Charging amps | 175
|
| Battery CCA | 600
|
| Battery volts | 12
|
| Battery Group | 1
|
| References |
 |
| 5700SL Series published in 2016, by Massey Ferguson |
| MF 5700 SL published in 2015, by Massey Ferguson |
| 5700SL Series Mid-Range Tractors published in 2016, by Massey Ferguson |
| MF 5700 SL Product Book published in 2015, by Massey Ferguson |
