Massey Ferguson 5S.115
|
|
| Production | |
| Manufacturer | Massey Ferguson (a part of AGCO) |
| Utility tractor | |
| Massey Ferguson 5S.115 Engine | |
| AGCO Power 4.4L 4-cyl diesel | |
| Fuel tank | 52.8 gal 199.8 L |
| Exhaust fluid (DEF) | 5.3 gal 20.1 L |
 Engine details ... | |
| Massey Ferguson 5S.115 Transmissions | |
| 16-speed four-speed power shift | |
| 24-speed six-speed power shift | |
 Transmission details ... |
| Massey Ferguson 5S.115 Power | |
| Engine | 115 hp 85.8 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | hydraulic front and rear |
| Power steering | |
| Electro-hydraulic wet disc brakes | |
| Trailer brakes | hydraulic OptOptional |
| pneumatic OptOptional | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the Massey Ferguson 5S.115 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| closed center OptOptional | |
| Pressure | 2901 psi 200.0 bar |
| Valves | 2 to 4 |
| Pump flow | 15.3 gpm (open) 57.9 lpm |
| 26.4 gpm (open optional) 99.9 lpm | |
| 29.1 gpm (closed) 110.1 lpm | |
| Steering flow | 8.5 gpm 32.2 lpm |
| Tractor hitch | |
| Rear Type | III |
| Control | position and draft control |
| Rear lift (at ends) | 13228 lbs 6000 kg |
| Front lift | 6614 lbs 3000 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Rear PTO Type | 540/540E |
| 540/540E/1000 | |
| Engine RPM | 540@1920 |
| 540E@1560 | |
| 1000@1960 | |
| Front PTO | independent OptOptional |
| Clutch | electro-hydraulic wet disc |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 100.4 inches 255 cm |
| Weight | 10582 lbs 4799 kg |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| MF 5S published in 2020, by Massey Ferguson |
