Tractors > Massey Ferguson > 5713S

Massey Ferguson 5713S



Massey Ferguson 5713S tractor photo
2017 - 2021
5700 S Series
Utility tractor
Series map:
5712S
5713S
115.0hp
125.0hp
Production
ManufacturerMassey Ferguson (a part of AGCO)
Utility tractor
Variants
5713Mbasic
5713Sdeluxe
Massey Ferguson 5713S Engine
AGCO Power 4.4L 4-cyl diesel
Fuel tank47.6 gal
180.2 L
Exhaust fluid (DEF)6.6 gal
25.0 L
Engine details ...
Massey Ferguson 5713S Transmissions
16-speed four-speed power shift
24-speed six-speed power shift
Transmission details ...
Massey Ferguson 5713S Power
Engine125 hp
93.2 kW
Engine (max)130 hp
96.9 kW
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic front and rear
Power steering
Hydraulic wet disc brakes
Trailer brakespneumatic
 hydraulic OptOptional
Cab standard with air-conditioning.
Photos
No photos of the Massey Ferguson 5713S are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
 closed center OptOptional
Pressure2901 psi
200.0 bar
Valves2 to 4
Pump flow15.3 gpm (open center)
57.9 lpm
 26.4 gpm (open center)OptOptional
99.9 lpm
 29 gpm (closed center)
109.8 lpm
Steering flow8.5 gpm
32.2 lpm
Tractor hitch
Rear TypeIII/II
Rear lift11464 lbs
5200 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000 (1.375)
Engine RPM540@1920
 540E@1560
 1000@1960
Dimensions & Tires
Wheelbase100.4 inches
255 cm
Weight10582 lbs
4799 kg
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
5713S references literature
MF 5700 S published in 2017, by Massey Ferguson
5700S Series published in 2020, by Massey Ferguson
