Production | |
Manufacturer: | LS |
Type: | Compact Utility tractor |
Variants | |
MT347: | ROPS shuttle |
MT347C: | Cab shuttle |
MT347H: | ROPS hydro |
MT347HC: | Cab hydro |
LS MT347 Power | |
Engine (gross): | 47 hp 35.0 kW |
Gear PTO (claimed): | 39.9 hp 29.8 kW |
Hydro PTO (claimed): | 37.6 hp 28.0 kW |
LS MT347 Engine | |
LS 1.9L 3-cyl diesel | |
ROPS Fuel tank: | 10.6 gal 40.1 L |
Cab Fuel tank: | 12.4 gal 46.9 L |
Engine details ... |
Mechanical | |
Chassis: | 4x4 MFWD 4WD |
Steering: | power |
Brakes: | wet disc |
Cab: | Two-post folding ROPS. Cab optional. |
Transmissions: | 16-speed synchro shuttle |
hydrostatic | |
Transmission details ... |
Photos | |
No photos of the LS MT347 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Hydraulics | |
Type: | open center |
Pressure: | 2466 psi 170.0 bar |
Valves: | 3 |
Pump flow: | 8.2 gpm 31.0 lpm |
ROPS shuttle Total flow: | 12.3 gpm 46.6 lpm |
ROPS hydro Total flow: | 14.3 gpm 54.1 lpm |
Cab hydro Total flow: | 15 gpm 56.8 lpm |
Gear Steering flow: | 4.1 gpm 15.5 lpm |
ROPS hydro Steering flow: | 6.2 gpm 23.5 lpm |
Cab hydro Steering flow: | 6.9 gpm 26.1 lpm |
Steering press.: | 2062 psi 142.2 bar |
Tractor hitch | |
Rear Type: | I |
Control: | position and draft control |
Rear lift (at ends): | 2755 lbs 1249 kg |
Rear lift (at 24"/610mm): | 2469 lbs 1119 kg |
Power Take-off (PTO) | |
Rear PTO: | independent |
Rear RPM: | 540 (1.375) |
Engine RPM: | 540@2409 |
Mid PTO: | independent*Optional |
Mid RPM: | 2000 |
Engine RPM: | 2000@2562 |
Dimensions & Tires | |
Wheelbase: | 73.2 inches 185 cm |
Weight: | 3869 to 4446 pounds |
Front tire: | 9.5-16 |
Rear tire: | 13.6-24 |
Full dimensions and tires ... |
LS MT347 attachments | |
front-end loader | |
backhoe | |
Attachment details ... |
Electrical | |
Ground: | negative |
Charging system: | alternator |
Charging amps: | 70 |
Charging volts: | 12 |
Battery volts: | 12 |
