Series: | MT342 | → MT347 |
Production | |
Manufacturer: | LS |
Type: | Compact Utility tractor |
LS MT342 Power | |
Engine (gross): | 42 hp 31.3 kW |
Shuttle PTO (claimed): | 33.6 hp 25.1 kW |
Hydro PTO (claimed): | 35.7 hp 26.6 kW |
LS MT342 Engine | |
LS 1.9L 3-cyl diesel | |
Fuel tank: | 7.4 gal 28.0 L |
Engine details ... |
Mechanical | |
Chassis: | 4x4 MFWD 4WD |
Steering: | power |
Brakes: | wet disc |
Cab: | Two-post folding ROPS. Cab optional. |
Transmissions: | 16-speed synchro shuttle |
hydrostatic | |
Transmission details ... |
Photos | |
LS MT342 photos... |
Hydraulics | |
Type: | open center |
Pressure: | 2466 psi 170.0 bar |
Valves: | 2 |
Pump flow: | 8.2 gpm 31.0 lpm |
ROPS shuttle Total flow: | 12.3 gpm 46.6 lpm |
ROPS hydro Total flow: | 14.3 gpm 54.1 lpm |
Cab hydro Total flow: | 15 gpm 56.8 lpm |
Shuttle Steering flow: | 4.1 gpm 15.5 lpm |
Hydro Steering flow: | 5.5 gpm 20.8 lpm |
Steering press.: | 2062 psi 142.2 bar |
Tractor hitch | |
Rear Type: | I |
Control: | position and draft control |
Rear lift (at ends): | 2755 lbs 1249 kg |
Rear lift (at 24"/610mm): | 2469 lbs 1119 kg |
Power Take-off (PTO) | |
Rear PTO: | independent |
Rear RPM: | 540 (1.375) |
Engine RPM: | 540@2409 |
Mid PTO: | independent*Optional |
Mid RPM: | 2000 |
Engine RPM: | 2000@2562 |
Dimensions & Tires | |
Wheelbase: | 73.2 inches 185 cm |
Weight: | 3869 to 4446 pounds |
Front tire: | 9.5-16 |
Rear tire: | 13.6-24 |
Full dimensions and tires ... |
LS MT342 attachments | |
front-end loader | |
backhoe | |
Attachment details ... |
Electrical | |
Ground: | negative |
Charging system: | alternator |
Charging amps: | 70 |
Charging volts: | 12 |
Battery volts: | 12 |
