LS MT352


No photo available
2020 -
MT3 Series
Compact Utility tractor
Series:MT347MT352MT357
Production
Manufacturer:LS
Type:Compact Utility tractor
Variants
MT352:ROPS shuttle
MT352C:Cab shuttle
MT352H:ROPS hydro
MT352HC:Cab hydro
LS MT352 Power
Engine (gross):52 hp
38.8 kW
Gear PTO (claimed):44.2 hp
33.0 kW
Hydro PTO (claimed):41.6 hp
31.0 kW
LS MT352 Engine
LS 1.9L 3-cyl diesel
ROPS Fuel tank:10.6 gal
40.1 L
Cab Fuel tank:12.4 gal
46.9 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Cab:Two-post folding ROPS. Cab optional.
Transmissions:16-speed synchro shuttle
 hydrostatic
Transmission details ...
Photos
No photos of the LS MT352 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
Pressure:2466 psi
170.0 bar
Valves:3
Pump flow:8.2 gpm
31.0 lpm
ROPS shuttle Total flow:12.3 gpm
46.6 lpm
ROPS hydro Total flow:14.3 gpm
54.1 lpm
Cab hydro Total flow:15 gpm
56.8 lpm
Gear Steering flow:4.1 gpm
15.5 lpm
ROPS hydro Steering flow:6.2 gpm
23.5 lpm
Cab hydro Steering flow:6.9 gpm
26.1 lpm
Steering press.:2062 psi
142.2 bar
Tractor hitch
Rear Type:I
Control:position and draft control
Rear lift (at ends):2756 lbs
1250 kg
Rear lift (at 24"/610mm):2469 lbs
1119 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540 (1.375)
Engine RPM:540@2409
Mid PTO:independent*Optional
Mid RPM:2000
Engine RPM:2000@2562
Dimensions & Tires
Wheelbase:73.2 inches
185 cm
Weight:3869 to 4446 pounds
Front tire:9.5-16
Rear tire:13.6-24
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:70
Charging volts:12
Battery volts:12
Page information
Last update:November 13, 2020
Copyright:Copyright 2020 TractorData LLC
