International Harvester 504 Hi-Clear
|
|
| Production | |
| Manufacturer | International Harvester |
| High-Clearance tractor | |
| Built in Rock Island, Illinois, USA | |
| Variants | |
| Farmall 504 | row-crop |
| IH 504 | utility |
| 504HC | high-clearance |
| IH 2504 | industrial |
| International Harvester 504 Hi-Clear Engines | |
| International Harvester 3.1L 4-cyl diesel | |
| International Harvester 2.5L 4-cyl gasoline | |
| Fuel tank | 15.3 gal 57.9 L |
 Engine details ... | |
| International Harvester 504 Hi-Clear Transmissions | |
| 5-speed unsynchronized gear | |
| 10-speed two-speed power shift | |
 Transmission details ... |
| International Harvester 504 Hi-Clear Power | |
| Drawbar (claimed) | 41 hp 30.6 kW |
| PTO (claimed) | 46 hp 34.3 kW |
| Mechanical | |
| Two-wheel drive | |
| Power steering | |
| Disc brakes | |
| Open operator station. |
| Hydraulics | |
| Type | open center |
| Valves | 1 or 2 |
| Pump flow | 12 gpm 45.4 lpm |
| Steering flow | 4.5 gpm 17.0 lpm |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 |
| Engine RPM | 540@2000 |
| Dimensions & Tires | |
| Wheelbase | 73 inches 185 cm |
| Weight | 4550 lbs 2063 kg |
| Front tire | 6.00-16 |
| Rear tire | 12.4-38 |
 Full dimensions and tires ... | |
| References | |
 | |
| 504 46hp. Tractors published by International Harvester | |
| Farm Equipment Reference Catalog published in 1965, by International Harvester |
