CaseIH Maxxum 135
|
|
| Series: | Maxxum 125 ← | Maxxum 135 | → Maxxum 145 |
| Production | |
| Manufacturer: | CaseIH |
| Type: | Utility tractor |
| Original price: | $113,498 (2017 ) |
| Variants | |
| Maxxum 135: | standard |
| Maxxum 135MC: | premium |
| CaseIH Maxxum 135 Power | |
| Engine (gross): | 135 hp 100.7 kW |
| Engine (max): | 169 hp 126.0 kW |
| PTO (claimed): | 110 hp 82.0 kW |
| Drawbar (tested): | 86.8 hp 64.7 kW |
| PTO (tested): | 131.0 hp 97.7 kW |
| CaseIH Maxxum 135 Engine | |
| FPT 4.5L 4-cyl diesel | |
 Engine details ... |
| Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Final drives: | inboard planetary |
| Steering: | power |
| Brakes: | hydraulic wet disc |
| Trailer brakes: | hydraulic*Optional |
| pneumatic*Optional | |
| Cab: | Cab standard with air-conditioning. |
| Transmission: | 16-speed partial power shift |
 Transmission details ... | |
| Photos | |
| No photos of the CaseIH Maxxum 135 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel: | 51.5 gal 194.9 L |
| 57.5 gal 217.6 L *Optional, with auxiliary tank. | |
| 60.8 gal 230.1 L *Optional, max tank. | |
| Exhaust fluid (DEF): | 10.4 gal 39.4 L |
| Hydraulic system: | 19.5 gal 73.8 L |
| Hydraulics | |
| Type: | open center |
| pressure-flow compensated*Optional | |
| Capacity: | 19.5 gal 73.8 L |
| Rear valves: | 2 to 4 |
| Mid valves: | 0 to 3 |
| Pump flow: | 21.1 gpm 79.9 lpm |
| 29.8 gpm 112.8 lpm *Optional, PFC system. | |
| SCV flow: | 19.8 gpm 74.9 lpm |
| Total flow: | 33.5 gpm 126.8 lpm |
| 42.2 gpm 159.7 lpm *With optional PFC system. | |
| Steering flow: | 12.4 gpm 46.9 lpm |
| Tractor hitch | |
| Rear Type: | II |
| IIIN/II*Optional | |
| Control: | electronic lower-link draft sensing |
| Rear lift (at 24"/610mm): | 6200 lbs 2812 kg |
| 6900 lbs 3129 kg *Optional | |
| Rear Arms: | telescopic link ends |
| Front Hitch: | optional |
| Drawbar: | Cat. 3 |
| Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540/1000 (1.375) |
| Front PTO: | independent*Optional |
| Clutch: | 1000:1895 |
| Front RPM: | 1000 (1.375) |
| Dimensions & Tires | |
| 2WD Wheelbase: | 104.4 inches 265 cm |
| 4WD Wheelbase: | 104 inches 264 cm |
| Weight: | 10825 to 11375 pounds |
| Front tire: | 380/85R28 |
| Rear tire: | 460/85R38 |
 Full dimensions and tires ... | |
| Electrical | |
| Charging amps: | 120 |
| 150*Optional | |
| 200*Optional | |
| Battery CCA: | 800 |
| 1300*Optional | |
| Battery volts: | 12 |
| Battery AH: | 176 |
