Tractors > CaseIH > Maxxum 135

CaseIH Maxxum 135 Tests



CaseIH Maxxum 135 tractor photo
2015 -
Maxxum Series
Utility tractor
Series map:
Maxxum 125
Maxxum 135
Maxxum 145
125.0hp
135.0hp
145.0hp
OCED Tractor Test 2973
Maxxum 135 fuel use from test 1095
OCED Tractor Test 2973
Diesel 16-speed 4WD
April 2016 - May 2016,
Link: OCED Tractor Test 2973 file
PTO performance
Max power131.0 hp
97.7 kW
Fuel use6.9 gal/hour
26.1 l/hour
Power at rated engine speed117.7 hp
87.8 kW
Fuel use6.9 gal/hour
26.1 l/hour
Power at rated PTO speed128.3 hp
95.7 kW
Fuel use7.0 gal/hour
26.5 l/hour
Drawbar performance
Max power86.8 hp
64.7 kW
Fuel use6.9 gal/hour
26.1 l/hour
Max pull11130 lbs
5048 kg
