CaseIH Maxxum 145


CaseIH Maxxum 145 tractor photo
2015 -
Maxxum Series
Utility tractor
Series map:
Maxxum 135
Maxxum 145
Maxxum 150
135.0hp
145.0hp
145.0hp
Production
ManufacturerCaseIH
Utility tractor
Original price was $119,606 in 2017
Variants
Maxxum 145standard
Maxxum 145MCpremium
CaseIH Maxxum 145 Power
Engine (gross)145 hp
108.1 kW
Engine (max)175 hp
130.5 kW
PTO (claimed)120 hp
89.5 kW
Mechanical
Two- or four-wheel drive
Final drivesinboard planetary
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic OptOptional
 pneumatic OptOptional
Cab standard with air-conditioning.
Photos
No photos of the CaseIH Maxxum 145 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel51.5 gal
194.9 L
 57.5 gal*Optional, with auxiliary tank.
217.6 L
 60.8 gal*Optional, max tank.
230.1 L
Exhaust fluid (DEF)10.4 gal
39.4 L
Hydraulic system19.5 gal
73.8 L
Hydraulics
Typeopen center
 pressure-flow compensated OptOptional
Capacity19.5 gal
73.8 L
Rear valves2 to 4
Mid valves0 to 3
Pump flow21.1 gpm
79.9 lpm
 29.8 gpm*Optional, PFC system.
112.8 lpm
SCV flow19.8 gpm
74.9 lpm
Total flow33.5 gpm
126.8 lpm
 42.2 gpm*With optional PFC system.
159.7 lpm
Steering flow12.4 gpm
46.9 lpm
Tractor hitch
Rear TypeII
 IIIN/II OptOptional
Controlelectronic lower-link draft sensing
Rear lift (at 24"/610mm)6200 lbs
2812 kg
 6900 lbsOptOptional
3129 kg
Rear Armstelescopic link ends
Front Hitchoptional
DrawbarCat. 3
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000 (1.375)
Front PTOindependent OptOptional
Clutch1000:1895
Front PTO Type1000 (1.375)
Dimensions & Tires
2WD Wheelbase104.4 inches
265 cm
4WD Wheelbase104 inches
264 cm
Weight12004 to 12555 pounds
Front tire380/85R28
Rear tire460/85R38
Full dimensions and tires ...
Electrical
Charging amps120
 150 OptOptional
 200 OptOptional
Battery CCA800
 1300 OptOptional
Battery volts12
Battery AH176
References
Maxxum 145 references literature
Maxxum Series Tractors published in 2016, by CaseIH
