New Holland TS110A



New Holland TS110A tractor photo
2003 - 2005
TS-A Series
Utility tractor
Series map:
TS100A
TS110A
TS115A
100.0hp
110.0hp
115.0hp
Production
ManufacturerNew Holland (a part of CNH)
Utility tractor
Built in Basildon, England
Variants
TS110A Deltaeconomy model
TS110A Pluspremium model
New Holland TS110A Engine
Iveco 4.5L 4-cyl diesel
Fuel tank47.6 gal
180.2 L
SuperSteer Fuel tank41.2 gal
155.9 L
Engine details ...
New Holland TS110A Transmissions
12-speed partially synchronized
24-speed two-speed power shift
16-speed four-speed power shift
Transmission details ...
New Holland TS110A Power
Engine (gross)110 hp
82.0 kW
Engine (max)143 hp
106.6 kW
PTO (claimed)90 hp
67.1 kW
Mechanical
Two- or four-wheel drive
Differential lockelectro-hydraulic rear
Power steering
Hydraulic wet disc brakes
Two-post folding ROPS. Cab available with air-conditioning.
Photos
No photos of the New Holland TS110A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
 closed-center load sensing OptOptional
Pressure3046 psi
210.0 bar
Rear valves2 to 4
Mid valves2 OptOptional
Pump flow16.6 gpm (open center)
62.8 lpm
 19.8 gpm (open center)
74.9 lpm
 26.5 gpm (closed center)
100.3 lpm
Steering flow10.5 gpm
39.7 lpm
Tractor hitch
Rear TypeII
Rear lift (at ends)17337.1 lbs
7864 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000 (1.375)
Engine RPM540@1969
 540E@1546
 1000@2120
Dimensions & Tires
2WD Wheelbase95 inches
241 cm
Terraglide Wheelbase95.3 inches
242 cm
SuperSteer Wheelbase99.2 inches
251 cm
Weight10560 lbs
4790 kg
Front tire7.50-16
2WD Rear tire16.9R38
Full dimensions and tires ...
TS110A Serial Numbers
Location:Serial number decal on the left side of the tractor, on the lower part of the radiator support bracket.
Electrical
Groundnegative
Charging systemalternator
ROPS Charging amps70
Cab Charging amps120
Battery volts12
References
TS110A references literature
TS-A Tractors published in 2003, by New Holland
TS-A Delta Tractors published in 2006, by New Holland
TS-A Plus Tractors published in 2006, by New Holland
Operator's Manual TS-A Series Tractors (82999130) published in 2005
