New Holland TS115



New Holland TS115 tractor photo
1998 - 2003
TS Series
Series map:
TS110
TS115
TS120
110.0hp
110.0hp
118.0hp
Production
ManufacturerNew Holland
Built in Basildon, England
New Holland TS115 Engine
New Holland 7.5L 6-cyl diesel
Fuel tank52.5 gal
198.7 L
Engine details ...
New Holland TS115 Transmissions
12-speed
24-speed
16-speed
Transmission details ...
New Holland TS115 Power
Engine110 hp
82.0 kW
PTO (claimed)95 hp
70.8 kW
Mechanical
Four-wheel drive
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.
Photos
New Holland TS115
New Holland TS115 photos...
Hydraulics
Typeopen center
 closed center OptOptional
Pressure2500 psi
172.4 bar
 2700 psi (open center)
186.2 bar
Valves2 to 4
Pump flow9.3 gpm
35.2 lpm
 17.4 gpm (optional pump)
65.9 lpm
 20 gpm (closed center)
75.7 lpm
Tractor hitch
Rear TypeII
Rear lift (at 24"/610mm)4200 lbs
1905 kg
 6210 lbs (assist ram)
2816 kg
 8240 lbs (two assist rams)
3737 kg
 8598 lbs (two rams, Elec draft control)
3900 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000 (1.375)
Engine RPM540@1900
 1000@2050 (non-shiftable)
 1000@2060 (shiftable)
Dimensions & Tires
Wheelbase103.3 inches
262 cm
Weight10449 lbs
4739 kg
Front tire13.6-24
Rear tire16.9-34
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps100
Charging volts12
Battery volts12
References
TS115 references literature
TS Tractors 70 to 90 hp published in 2000, by New Holland
Series TS published in 2000, by New Holland
TS90 TS100 TS110 TS115 Operator's Manual (86630281) published in 2001
