New Holland TS120



New Holland TS120 tractor photo
1998 - 2003
TS Series
Utility tractor
Series map:
TS115
TS120
82.0kw
88.0kw
Production
ManufacturerNew Holland
Utility tractor
Built in Curitiba, Brazil
New Holland TS120 Engine
New Holland 7.5L 6-cyl diesel
Fuel tank39.6 gal
149.9 L
Engine details ...
New Holland TS120 Transmissions
16-speed gear
12-speed
Transmission details ...
New Holland TS120 Power
Engine118 hp
88.0 kW
Mechanical
Four-wheel drive
Final drivesmechanical rear
 electrohydraulic rear OptOptional
Power steering
Wet disc brakes
Two-post folding ROPS. Cab optional with air-conditioning.
Photos
No photos of the New Holland TS120 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2611 psi
180.0 bar
Pump flow9.3 gpm
35.2 lpm
 17.4 gpmOptOptional
65.9 lpm
Tractor hitch
Rear TypeII
Controlposition and draft control
Rear lift (at 24"/610mm)11003 lbs
4990 kg
 14484 lbsOptOptional
6569 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000 (1.375)
Dimensions & Tires
Wheelbase103.3 inches
262 cm
Weight10450 lbs
4740 kg
Front tire14.9-28
Rear tire18.4-38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
TS120 references literature
TS Models TS 90, TS 110 & TS 120 published by New Holland
