CaseIH Farmall 120A
| 2012 - 2023 |
|
Farmall 100A Series | Utility tractor |
|
Production |
Manufacturer: | CaseIH
|
Type: | Utility tractor
|
CaseIH Farmall 120A Power |
Engine (gross): | 118 hp 88.0 kW
|
PTO (claimed): | 96 hp 71.6 kW
|
Drawbar (tested): | 86.68 hp 64.6 kW
|
PTO (tested): | 104.48 hp 77.9 kW
|
power test details ... |
Mechanical |
Chassis: | 4x2 2WD
|
| 4x4 MFWD 4WD
|
Steering: | power
|
Brakes: | wet disc
|
Cab: | Two-post foldable ROPS. Cab optional with air-conditioning.
|
Transmissions: | 8-speed power shuttle
|
| 8-speed synchronized shuttle
|
| 16-speed power shuttle
|
Transmission details ... |
Photos |
No photos of the CaseIH Farmall 120A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Capacity |
Fuel: | 40 gal 151.4 L
|
Hydraulic system: | 16.4 gal 62.1 L
|
Hydraulics |
Type: | open center
|
Capacity: | 16.4 gal 62.1 L
|
Valves: | 2 to 4
|
Pump flow: | 22 gpm 83.3 lpm
|
Total flow: | 31 gpm 117.3 lpm
|
Steering flow: | 9 gpm 34.1 lpm
|
Tractor hitch |
Rear Type: | II
|
Rear lift (at 24"/610mm): | 7200 lbs 3265 kg
|
Power Take-off (PTO) |
Rear PTO: | independent
|
Rear RPM: | 540/1000
|
Electrical |
Ground: | negative
|
Charging system: | alternator
|
Charging amps: | 120
|
Battery CCA: | 950
|
Battery volts: | 12
|
