CaseIH Farmall 125A

CaseIH Farmall 125A tractor photo
2012 - 2014
Farmall 100A Series
Utility tractor
Series:Farmall 120AFarmall 125AFarmall 140A
Farmall 130A
Type:Utility tractor
CaseIH Farmall 125A Power
Engine (gross):125 hp
93.2 kW
PTO (claimed):105 hp
78.3 kW
Drawbar (tested):94.27 hp
70.3 kW
PTO (tested):108.95 hp
81.2 kW
power test details ...
Chassis:4x2 2WD
 4x4 MFWD 4WD
Brakes:wet disc
Cab:Two-post foldable ROPS. Cab optional with air-conditioning.
Transmissions:8-speed power shuttle
 8-speed synchronized shuttle
 16-speed power shuttle
Transmission details ...
No photos of the CaseIH Farmall 125A are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Fuel:62 gal
234.7 L
Hydraulic system:16.4 gal
62.1 L
Type:open center
Capacity:16.4 gal
62.1 L
Valves:2 to 4
Pump flow:22 gpm
83.3 lpm
Total flow:31 gpm
117.3 lpm
Steering flow:9 gpm
34.1 lpm
Tractor hitch
Rear Type:II
Rear lift (at 24"/610mm):7200 lbs
3265 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
Dimensions & Tires
2WD Wheelbase:105 inches
266 cm
4WD Wheelbase:104 inches
264 cm
Weight:9061 to 10406 pounds
Full dimensions and tires ...
Charging system:alternator
Charging amps:120
Battery CCA:950
Battery volts:12
