Tractors > CaseIH > Farmall 120A

CaseIH Farmall 120A Tests



CaseIH Farmall 120A tractor photo
2012 - 2025
Model year
Farmall 100A Series
Utility tractor
Series map:
Farmall 110A
Farmall 120A
Farmall 125A
110.0hp
118.0hp
125.0hp
OCED Tractor Test 2052A
Farmall 120A fuel use from test 865A
OCED Tractor Test 2052A
Diesel 8-speed 4WD
December 3 - 6, 2012
Link: OCED Tractor Test 2052A file
PTO performance
Max power104.48 hp
77.9 kW
Fuel use6.3 gal/hour
23.8 l/hour
Power at rated engine speed97.27 hp
72.5 kW
Fuel use7.2 gal/hour
27.3 l/hour
Power at rated PTO speed101.23 hp
75.5 kW
Fuel use6.9 gal/hour
26.1 l/hour
Drawbar performance
Max power86.68 hp
64.6 kW
Fuel use7.2 gal/hour
27.3 l/hour
Max pull7698 lbs
3491 kg
