New Holland Boomer 35
|
|
| Production | |
| Manufacturer | New Holland |
| Compact Utility tractor | |
| Original price was $16,531 in 2010 | |
| New Holland Boomer 35 Engine | |
| Mitsubishi 1.8L 4-cyl diesel | |
| Fuel tank | 8.7 gal 32.9 L |
 Engine details ... | |
| New Holland Boomer 35 Transmissions | |
| 12-speed synchronized shuttle | |
| hydrostatic | |
 Transmission details ... |
| New Holland Boomer 35 Power | |
| Engine (gross) | 38 hp 28.3 kW |
| Gear PTO (claimed) | 32.2 hp 24.0 kW |
| Hydro PTO (claimed) | 30.3 hp 22.6 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Differential mechanical wet disc brakes | |
| Two-post folding ROPS. | |
| Photos | |
| No photos of the New Holland Boomer 35 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Rear valves | 1 OptOptional |
| Mid valves | 2 OptOptional |
| Pump flow | 8.2 gpm 31.0 lpm |
| Total flow | 12.3 gpm 46.6 lpm |
| Steering flow | 4.1 gpm 15.5 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift (at ends) | 1807 lbs 819 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 540 (1.375) |
| Mid PTO | independent OptOptional |
| Mid PTO Type | 2000 |
| Dimensions & Tires | |
| Wheelbase | 66 inches 167 cm |
| Weight | 2913 lbs 1321 kg |
| Front tire | 7-14 |
| Rear tire | 11.2-24 |
 Full dimensions and tires ... | |
| New Holland Boomer 35 attachments | |
| 66" mid-mount mower deck | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 50 |
| Charging volts | 12 |
| Battery CCA | 660 |
| Battery volts | 12 |
| Battery AH | 80 |
| References | |
 | |
| New Boomer Compact Tractors published in 2010, by New Holland |
