New Holland Boomer 35
| 2011 - 2013 |
Boomer Series | Compact Utility tractor |
|
Production |
Manufacturer: | New Holland
|
Type: | Compact Utility tractor
|
New Holland Boomer 35 Power |
Engine (gross): | 38 hp 28.3 kW
|
PTO (claimed): | 32.2 hp 24.0 kW (gear)
|
| 30.3 hp 22.6 kW (hydro)
|
Mechanical |
Chassis: | 4x4 MFWD 4WD
|
Differential lock: | mechanical foot-activated
|
Steering: | hydrostatic power
|
Brakes: | differential mechanical wet disc
|
Cab: | Two-post foldable ROPS.
|
Transmissions: | 12-speed synchronized shuttle
|
| hydrostatic
|
Transmission details ... |
Photos |
No photos of the New Holland Boomer 35 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Hydraulics |
Type: | open center
|
Valves: | 0 to 2
|
Pump flow: | 8.2 gpm 31.0 lpm
|
Total flow: | 12.3 gpm 46.6 lpm
|
Steering flow: | 4.1 gpm 15.5 lpm
|
Tractor hitch |
Rear Type: | I
|
Rear lift (at ends): | 1,807 lbs 819 kg
|
Power Take-off (PTO) |
Rear PTO: | independent
|
Clutch: | electro-hydraulic
|
Rear RPM: | 540
|
Mid PTO: | optional independent
|
Mid RPM: | 2000
|
Electrical |
Ground: | negative
|
Charging system: | alternator
|
Charging amps: | 50
|
Charging volts: | 12
|
Battery CCA: | 660
|
Battery volts: | 12
|
Battery AH: | 80
|
Page information |
Last update: | December 3, 2014
|
