Tractors > New Holland > Boomer 30

New Holland Boomer 30

New Holland Boomer 30 tractor photo
2011 - 2013   Boomer Series
Compact Utility tractor
Next model:New Holland Boomer 33
Series next:New Holland Boomer 35



Manufacturer:New Holland

New Holland Boomer 30 Engine:

   Mitsubishi 1.5L 4-cyl diesel
full engine details ...



3-Point Hitch:

Rear Type:I
Rear lift (at ends):1,807 lbs [819 kg]

Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540
Mid PTO:optional independent
Mid RPM:2000

Dimensions & Tires:

Wheelbase:66 inches [167 cm]
Weight:2,913 lbs [1321 kg]
full dimensions and tires ...

New Holland Boomer 30 attachments:

 front-end loader
all Boomer 30 attachments ...

Boomer 30 Serial Numbers:

- Serial numbers unknown -

New Holland Boomer 30 Power:

Engine (gross):28 hp [20.9 kW]
PTO (claimed):23.9 hp [17.8 kW] (gear)
 22.5 hp [16.8 kW] (hydro)


Chassis:4x4 MFWD 4WD
Differential lock:mechanical foot-activated
Steering:hydrostatic power
Brakes:differential mechanical wet disc
Cab:Two-post foldable ROPS.


Type:open center
Valves:0 to 2
Pump flow:8.2 gpm [31.0 lpm]
Total flow:12.3 gpm [46.6 lpm]
Steering flow:4.1 gpm [15.5 lpm]


Charging system:alternator
Charging amps:50
Charging volts:12


Cold-cranking amps:660
