Ford 4610SU
| | 1981 - 1989 |
| 10 Utility Series | | Utility tractor |
|
| Production |
| Manufacturer | Ford
|
| Utility tractor |
| The Ford 4610SU fitted the 4610 engine into a 3610 frame. |
| Ford 4610SU Power |
| Engine (gross) | 63 hp
47.0 kW
|
| Engine | 60 hp
44.7 kW
|
| PTO (claimed) | 52 hp
38.8 kW
|
| Drawbar (tested) | 44.28 hp
33.0 kW
|
| PTO (tested) | 52.52 hp
39.2 kW
|
 Performance test details ... |
| Mechanical |
| Two-wheel drive |
| Final drives | inboard planetary
|
| Differential lock | mechanical rear
|
| Power steering |
| Differential wet disc brakes |
| Two-post fixed ROPS. |
| Capacity |
| Fuel | 13 gal
49.2 L
|
| Hydraulic system | 12.1 gal
45.8 L
|
| Steering | 3.6 qts
3.4 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 12.1 gal
45.8 L
|
| Pressure | 2500 psi
172.4 bar
|
| Pump flow | 8.5 gpm
32.2 lpm
|
| Steering cap. | 3.6 qts
3.4 L
|
| Tractor hitch |
| Rear Type | II/I
|
| Control | position and draft control
|
| Rear lift (at 24"/610mm) | 3080 lbs
1397 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540
|
| Engine RPM | 540@1800
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Mk I Charging amps | 32
|
| Mk II Charging amps | 51
|
| Battery volts | 12
|
| Diesel Battery AH | 128
|
| Gas Battery AH | 77
|
| References |
 |
| Farm Loaders published in 1982, by Ford |
| Farm Loaders published in 1988, by Ford |
| Front-end Loaders published in 1989, by Ford |
| Front-end Loaders published in 1992, by Ford |
| 34-52 hp Tractors published in 1982, by Ford |
| 32-52 hp Tractors published in 1985, by Ford |
| 32-52 hp Tractors published in 1986, by Ford |
| 32-52 hp Tractors published in 1987, by Ford |
| If you're looking for tractor quality, look to Ford published in 1982 |
| Salesman's Reference published in 1981, by Ford |
| Sales Reference Guide published in 1986, by Ford |
