Ford 4610


Ford 4610 tractor photo
1981 - 1989
10 Utility Series
Utility tractor
4600
Series:41104610
4630
Production
Manufacturer:Ford
Type:Utility tractor
Original price:$18,200 (1989 )
Variants
4610:utility frame
4610SU:small frame
4610H:highway
4910 LCG:mowing tractor
4610N:narrow
4610NO:narrow low
4610O:low-profile
Ford 4610 Power
Engine (gross):63 hp
47.0 kW
Engine:60 hp
44.7 kW
PTO (claimed):52 hp
38.8 kW
Plows:4
Drawbar (tested):44.28 hp
33.0 kW
PTO (tested):52.52 hp
39.2 kW
power test details ...
Ford 4610 Engines
Ford 3.3L 3-cyl diesel
Ford 3.3L 3-cyl gasoline
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Final drives:inboard planetary
Differential lock:mechanical rear
Steering:power assist
Brakes:differential wet disc
Cab:Two-post fixed ROPS. Cab optional.
Transmissions:8-speed
 8-speed synchromesh
Transmission details ...
Capacity
Fuel:16 gal
60.6 L
Hydraulic system:12.1 gal
45.8 L
Steering:3.6 qts
3.4 L
Hydraulics
Type:open center
Capacity:12.1 gal
45.8 L
Valves:1
Pump flow:8.5 gpm
32.2 lpm
 14.1 gpm
53.4 lpm *Optional dual pump.
Steering cap.:3.6 qts
3.4 L
Tractor hitch
Rear Type:II/I
Control:position and top-link draft control
Rear lift (at 24"/610mm):3080 lbs
1397 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
Engine RPM:540@1800
Dimensions & Tires
2WD Wheelbase:84.5 inches
214 cm
4WD Wheelbase:84.1 inches
213 cm
Weight:4806 lbs
2180 kg
Front tire:7.50-16
Rear tire:14.9-28
Full dimensions and tires ...
4610 Serial Numbers
Location:Plate inside engine compartment and front-right transmission cover
1982:C681910
1983:C695880
1984:C713459
1985:C737800
1986:C754100
1987:C768000
1987:BA80100
1988:BB06622
1988:BB31777
1989:BB80620
1990:BC26239

how to read serial numbers...

Electrical
Ground:negative
Charging system:alternator
Mk I Charging amps:32
Mk II Charging amps:51
Battery volts:12
Diesel Battery AH:128
Gas Battery AH:77
