SAME Dorado 75


SAME Dorado 75 tractor photo
2000 - 2004
Dorado Series
Utility tractor
Production
ManufacturerSAME
Utility tractor
Built in Italy
SAME Dorado 75 Engine
SAME 4.0L 4-cyl diesel
Fuel tank23.8 gal
90.1 L
Engine details ...
SAME Dorado 75 Transmissions
16-speed
20-speed
45-speed three-speed power shift
Transmission details ...
SAME Dorado 75 Power
Engine72 hp
53.7 kW
Mechanical
Two- or four-wheel drive
Differential lockelectro-hydraulic
Power steering
Hydraulic wet disc brakes
Two-post ROPS. Cab optional with available air-conditioning.
Photos
No photos of the SAME Dorado 75 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Valves2
Pump flow9.5 gpm
36.0 lpm
 12.7 gpmOptOptional
48.1 lpm
Tractor hitch
Rear TypeII
Controlposition and draft control
Rear lift6394 lbs
2900 kg
 7939 lbsOptOptional
3601 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000 (1.375)
Dimensions & Tires
2WD Wheelbase88 inches
223 cm
4WD Wheelbase86.1 inches
218 cm
Weight5490 to 6371 pounds
Front tire7.50-16
2WD Rear tire420/70R30
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
Dorado 75 references literature
Dorado 55-65-75-85 published in 2001, by SAME
