SAME Dorado 65


SAME Dorado 65 tractor photo
1999 - 2004
Dorado Series
Utility tractor
Production
ManufacturerSAME
Utility tractor
Built in Italy
SAME Dorado 65 Engine
SAME 3.0L 3-cyl diesel
Fuel tank23.8 gal
90.1 L
Engine details ...
SAME Dorado 65 Transmissions
16-speed
20-speed
45-speed three-speed power shift
Transmission details ...
SAME Dorado 65 Power
Engine63 hp
47.0 kW
Mechanical
Two- or four-wheel drive
Differential lockelectro-hydraulic
Power steering
Hydraulic wet disc brakes
Two-post ROPS. Cab optional with available air-conditioning.
Photos
No photos of the SAME Dorado 65 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Valves2
Pump flow9.5 gpm
36.0 lpm
 12.7 gpmOptOptional
48.1 lpm
Tractor hitch
Rear TypeII
Controlposition and draft control
Rear lift6394 lbs
2900 kg
 7939 lbsOptOptional
3601 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000 (1.375)
Dimensions & Tires
2WD Wheelbase82.9 inches
210 cm
4WD Wheelbase80.9 inches
205 cm
Weight5291 to 6283 pounds
Front tire7.50-16
2WD Rear tire420/70R28
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
Dorado 65 references literature
Dorado 55-65-75-85 published in 2001, by SAME
