SAME Dorado 70


SAME Dorado 70 tractor photo
1995 - 2000
Dorado Series
Utility tractor
Series map:
Dorado 60
Dorado 70
44.7kw
52.2kw
Production
ManufacturerSAME
Utility tractor
Built in Italy
SAME Dorado 70 Engine
SAME 4.0L 4-cyl diesel
Fuel tank23.8 gal
90.1 L
Engine details ...
SAME Dorado 70 Power
Engine70 hp
52.2 kW
Mechanical
Two- or four-wheel drive
Differential lockelectrohydraulic rear
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic
Two-post ROPS. Cab available with optional air-conditioning.
Photos
No photos of the SAME Dorado 70 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow9.5 gpm
36.0 lpm
 12.7 gpmOptOptional
48.1 lpm
Tractor hitch
Rear TypeII
Controlposition and draft control
Rear lift6393 lbs
2899 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000 (1.375)
Front PTOindependent OptOptional
Front PTO Type1000
Dimensions & Tires
2WD Wheelbase88 inches
223 cm
4WD Wheelbase86.1 inches
218 cm
Weight5489 to 6371 pounds
Front tire7.50-18
2WD Rear tire16.9R30
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
Dorado 70 references literature
Dorado 60/70 published in 1998, by SAME
