SAME Dorado 76


SAME Dorado 76 tractor photo
2005 - 2009
Dorado Series
Utility tractor
Series map:
Dorado 66
Dorado 76
Dorado 86
50.0kw
52.2kw
61.9kw
Production
ManufacturerSAME
Utility tractor
Built in Italy
SAME Dorado 76 Engine
SAME 4.0L 4-cyl diesel
Fuel tank23.8 gal
90.1 L
Engine details ...
SAME Dorado 76 Transmissions
20-speed
45-speed three-speed power shift
Transmission details ...
SAME Dorado 76 Power
Engine (gross)74 hp
55.2 kW
Mechanical
Two- or four-wheel drive
Differential lockelectro-hydraulic
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic
Two-post ROPS. Cab optional with air-conditioning.
Photos
No photos of the SAME Dorado 76 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Valves2
Pump flow14.3 gpm
54.1 lpm
Tractor hitch
Rear lift6614 lbs
3000 kg
 7937 lbsOptOptional
3600 kg
Front lift3858 lbs
1749 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000 (1.375)
Front PTOindependent
Clutchelectro-hydraulic wet disc
Front PTO Type1000
Dimensions & Tires
2WD Wheelbase88.4 inches
224 cm
4WD Wheelbase86 inches
218 cm
Weight5512 to 6393 pounds
Rear tire720/70R30
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
Dorado 76 references literature
Dorado 56-66-76-86 published in 2004, by SAME
