CaseIH MXU125


CaseIH MXU125 tractor photo
2004 - 2006
MXU Maxxum Series
Utility tractor
Series map:
MXU115
MXU125
MXU135
116.0hp
125.0hp
135.0hp
Production
ManufacturerCaseIH
Utility tractor
Built in Basildon, England
Original price was $52,400 in 2005
Variants
TS125Asimilar New Holland model
CaseIH MXU125 Engine
CNH 6.7L 6-cyl diesel
Fuel tank67 gal
253.6 L
Engine details ...
CaseIH MXU125 Transmissions
24-speed partial powershift
16-speed partial powershift
Transmission details ...
CaseIH MXU125 Power
Engine (gross)125 hp
93.2 kW
PTO (claimed)105 hp
78.3 kW
Drawbar (tested)88.5 hp
66.0 kW
PTO (tested)121.2 hp
90.4 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Final drivesplanetary inboard
Differential lockelectro-hydraulic rear standard
 front optional
Power steering
Differential hydraulic wet disc brakes
Two-post ROPS. Cab optional.
Photos
No photos of the CaseIH MXU125 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
 pressure-flow compensated (PFC)OptOptional
Pressure2974 psi
205.1 bar
 3118 psi (PFC)
215.0 bar
Rear valves2 to 4
Pump flow19.8 gpm
74.9 lpm
 26.5 gpm (PFC)
100.3 lpm
Total flow30.3 gpm
114.7 lpm
 37 gpm (PFC)
140.0 lpm
Steering flow10.5 gpm
39.7 lpm
Tractor hitch
Rear TypeII (ROPS)
 II/IIIN (cab)
Controlmechanical lower link (ROPS)
 electronic draft control (cab)
Rear lift9,285 lbs
4211 kg
 12,185 lbs (with cab)
5527 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet plates
Rear RPM540/1000
Engine RPM540@1969
1000@2120
Dimensions & Tires
2WD Wheelbase104.4 inches
265 cm
4WD Wheelbase104.7 inches
265 cm
Weight10053 to 12065 pounds
Front tire10.00x16
2WD Rear tire18.4R38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps70 (ROPS)
 120 (cab)
Battery CCA1300
Battery volts12
References
MXU125 references literature
MXU Series Maxxum Tractors published in 2004, by CaseIH
MXU Series Maxxum Tractors published in 2005, by CaseIH
TS1610-TS2810
TS1610-TS1910-TD2202-TD2205
