Tractors > CaseIH > MXU130 Value

CaseIH MXU130 Value



No photo available
2005 - 2006
MXU Maxxum Series
Utility tractor
Series map:
MXU125
MXU130
MXU135
125.0hp
131.0hp
135.0hp
Production
ManufacturerCaseIH
Utility tractor
Built in Basildon, England
CaseIH MXU130 Engine
CNH 6.7L 6-cyl diesel
Fuel tank67 gal
253.6 L
Engine details ...
CaseIH MXU130 Transmission
16-speed partial powershift
Transmission details ...
CaseIH MXU130 Power
Engine (gross)131 hp
97.7 kW
PTO (claimed)110 hp
82.0 kW
Mechanical
Two- or four-wheel drive
Final drivesplanetary inboard
Differential lockelectro-hydraulic
Steeringhydrostatic power
Differential hydraulic wet disc brakes
ROPS. Cab optional.
Photos
No photos of the CaseIH MXU130 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Valves2 to 3
Pump flow16.6 gpm
62.8 lpm
Total flow27.1 gpm
102.6 lpm
Steering flow10.5 gpm
39.7 lpm
Tractor hitch
Rear Type2
Controlmechanical lower link
Rear lift (at 24"/610mm)7,509 lbs
3406 kg
 8,813 lbs (optional)
3997 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000 (1.375)
Dimensions & Tires
2WD Wheelbase104.4 inches
265 cm
4WD Wheelbase104.7 inches
265 cm
Weight10060 to 11406 pounds
Front tire10.00x16
Rear tire18.4R38 (2WD)
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps120
Battery CCA800
 960 (optional)
Battery volts12
References
MXU130 Value references literature
MXU Series Maxxum Tractors published in 2005, by CaseIH
