Tractors > CaseIH > 8940

CaseIH 8940 Tests



CaseIH 8940 tractor photo
1997 - 1998
Magnum 8900 Series
Row-Crop tractor
Series map:
8930
8940
8950
200.0hp*
227.8hp*
250.0hp*
*Estimated engine power for comparison only.
OCED Tractor Test 1736
8940 fuel use from test 236
OCED Tractor Test 1736
Diesel 18-speed 4WD
September 16 - 29, 1997
Link: OCED Tractor Test 1736 file
PTO performance
Max power230.83 hp
172.1 kW
Fuel use12.5 gal/hour
47.3 l/hour
Power at rated engine speed206.81 hp
154.2 kW
Fuel use12.4 gal/hour
46.9 l/hour
Drawbar performance
Max power176.35 hp
131.5 kW
Fuel use12.4 gal/hour
46.9 l/hour
Gear 7 used for power test.
Max pull18061 lbs
8192 kg
Gear 5 used for pull test.
