John Deere 4250
| | 1983 - 1988 |
| 50 Series | | Row-Crop tractor |
|
Series map:
4050
4250
4450
130.0hp
144.0hp
158.2hp
| Production |
| Manufacturer | John Deere
|
| Row-Crop tractor |
| Built in Waterloo, Iowa, USA |
| Original price | $43,341 (1983 Quad-Range ROPS 2WD )
|
| $63,597 (1983 Power Shift Cab 4WD )
|
| John Deere 4250 Power |
| Engine | 144 hp
107.4 kW
|
| Drawbar (claimed) | 101 hp
75.3 kW
|
| PTO (claimed) | 120 hp
89.5 kW
|
| Drawbar (tested) | 106.38 hp
79.3 kW
|
| PTO (tested) | 120.86 hp
90.1 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Final drives | inboard planetary
|
| Differential lock | hydraulic rear
|
| Power steering |
| Differential hydraulic wet disc brakes |
| Sound-Gard cab standard. Optional four-post Roll-Gard ROPS. |
| Capacity |
| Fuel | 65 gal
246.0 L
|
| Hydraulic system | 10.5 gal (2WD Power Shift)
39.7 L
|
| | 13.5 gal (4WD Power Shift)
51.1 L
|
| | 16.0 gal (Quad-Range)
60.6 L
|
| Hydraulics |
| Type | closed center
|
| Capacity | 10.5 gal (2WD Power Shift)
39.7 L
|
| | 13.5 gal (4WD Power Shift)
51.1 L
|
| | 16.0 gal (Quad-Range)
60.6 L
|
| Pressure | 2277 psi
157.0 bar
|
| Valves | 2 or 3
|
| Pump flow | 26.5 gpm
100.3 lpm
|
| Tractor hitch |
| Rear Type | IIIN/II
|
| Control | lower-link draft sensing
|
| Rear lift | 6,290 lbs
2853 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | hydraulic wet disc
|
| Rear RPM | 540/1000
|
| Engine RPM | 540@2200
1000@2200
|
| 4250 Serial Location |
 |
| The rear of the tractor. |
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 72
|
| | 90 (with Sound-Gard cab)
|
| Batteries | 2
|
| Battery volts | 6
|
| | 12 OptOptional
|
| References |
 |
| Loaders, Spreaders and Blades published in 1984, by John Deere |
| Tractors 100 to 190 HP published in 1984, by John Deere |
| Tractors 105 to 190 HP published in 1984, by John Deere |
| Row-Crop Tractors Product Information Handbook published in 1984, by John Deere |
| Row-Crop Tractors Product Information Handbook published in 1986, by John Deere |
| Mechanical Front-Wheel Drive published in 1984, by John Deere |
| Agricultural Price List published in 1983, by John Deere |
