John Deere 4450
|
|
| Production | |
| Manufacturer | John Deere |
| Row-Crop tractor | |
| Built in Waterloo, Iowa, USA | |
| Original price | $46,670 (1983 Quad-Range ROPS 2WD ) |
| $67,009 (1983 Power Shift Cab 4WD ) | |
| The John Deere 4450 was the best-selling model of the entire 50-series line of tractors. The 4450 alone accounted for 20% of sales in the line. John Deere introduced its Caster/Action front-wheel drive system on these tractors. By enabling the tractors' front wheels to angle up to 13-degrees, sharper turn angles and larger front tires could be used. | |
| John Deere 4450 Engine | |
| John Deere 7.6L 6-cyl diesel | |
 Engine details ... |
| John Deere 4450 Transmissions | |
| 16-speed partial power shift | |
| 15-speed full power shift | |
 Transmission details ... |
| John Deere 4450 Power | |
| Engine | 158.2 hp 118.0 kW |
| Drawbar (claimed) | 121 hp 90.2 kW |
| PTO (claimed) | 140 hp 104.4 kW |
| Drawbar (tested) | 120.11 hp 89.6 kW |
| PTO (tested) | 140.43 hp 104.7 kW |
 Performance test details ... | |
| Mechanical | |
| Two- or four-wheel drive | |
| Final drives | inboard planetary |
| Differential lock | hydraulic rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Sound-Gard cab standard. Optional four-post Roll-Gard ROPS. | |
| Photos | |
 | |
 John Deere 4450 photos... | |
| Capacity | |
| Fuel | 65 gal 246.0 L |
| Hydraulic system | 10.5 gal (2WD Power Shift) 39.7 L |
| 13.5 gal (4WD Power Shift) 51.1 L | |
| 16.0 gal (Quad-Range) 60.6 L | |
| Hydraulics | |
| Type | closed center |
| Capacity | 10.5 gal (2WD Power Shift) 39.7 L |
| 13.5 gal (4WD Power Shift) 51.1 L | |
| 16.0 gal (Quad-Range) 60.6 L | |
| Pressure | 2277 psi 157.0 bar |
| Valves | 2 or 3 |
| Pump flow | 26.5 gpm 100.3 lpm |
| Tractor hitch | |
| Rear Type | IIIN/II |
| Control | lower-link draft sensing |
| Rear lift | 6294 lbs 2854 kg |
| 7418 lbsOptOptional 3364 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | hydraulic wet disc |
| Rear RPM | 540/1000 |
| Engine RPM | 540@2200 1000@2200 |
| Dimensions & Tires | |
| 2WD Wheelbase | 106.7 inches 271 cm |
| 4WD Wheelbase | 105.3 inches 267 cm |
| Weight | 12745 to 15400 pounds |
| Front tire | 10.00-16 |
| 2WD Rear tire | 18.4-38 |
 Full dimensions and tires ... | |
| John Deere 4450 attachments | |
| front-end loader | |
 Attachment details ... |
| 4450 Serial Numbers | |
| 1983 | 1000 |
| 1984 | 11001 |
| 1985 | 18001 |
| 1986 | 22001 |
| 1987 | 24001 |
| 1988 | 26001 |
| 1989 | 31001 |
FAQ: How to read a serial number table. | |
| 4450 Serial Location | |
 | |
| Serial number plate on rear of tractor. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 72 |
| 90 *With Sound-Gard cab | |
| Batteries | 2 |
| Battery volts | 6 |
| 12 OptOptional | |
| References | |
 | |
| Loaders, Spreaders and Blades published in 1984, by John Deere | |
| Tractors 100 to 190 HP published in 1984, by John Deere | |
| Tractors 105 to 190 HP published in 1984, by John Deere | |
| Row-Crop Tractors Product Information Handbook published in 1984, by John Deere | |
| Row-Crop Tractors Product Information Handbook published in 1986, by John Deere | |
| Mechanical Front-Wheel Drive published in 1984, by John Deere | |
| Agricultural Price List published in 1983, by John Deere |
