Tractors > CaseIH > MX240 Magnum

CaseIH MX240 Magnum - transmission

CaseIH MX240 Magnum tractor photo
1999 - 2002   Magnum Series
Row-Crop tractor
Previous model:CaseIH 8940
Next model:CaseIH MX255
Series next:CaseIH MX270
Series back:CaseIH MX220
more CaseIH MX240 Magnum specifications...






Transmission:

Type:full powershift
Gears:18 forward and 4 reverse
Clutch:electro-hydrauliclly actuated wet discs
Speeds:
MX240 Magnum  full powershift speeds


Transmission:

Gears:24 forward and 6 reverse
