CaseIH MX220 Magnum Transmission


CaseIH MX220 Magnum tractor photo
1999 - 2002
Magnum Series
Row-Crop tractor
8930
Series:MX200MX220 MagnumMX240
MX230
Transmissions overview
18-speed full powershift
24-speed
Transmission
Type:full powershift
Gears:18 forward and 4 reverse
Clutch:electro-hydrauliclly actuated wet discs
Speeds
MX220 Magnum  full powershift speeds
Transmission
Gears:24 forward and 6 reverse
