Kubota F2510
| | 2025 - |
| F 10 Series | | Front-mount mower |
|
Series map:
F2510
F3710
23.3hp
36.9hp
| Production |
| Manufacturer | Kubota
|
| Front-mount mower |
| Original price was $24,199 in 2025 |
| Mechanical |
| Drive | 4x2 2WD
|
| | 4x4 4WD
|
| Differential lock | mechanical front
|
| Power steering |
| Wet disc brakes |
| Two-post folding ROPS. |
| Photos |
| No photos of the Kubota F2510 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 16.1 gal
60.9 L
|
| Hydraulic system | 3.7 gal
14.0 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 3.7 gal
14.0 L
|
| Pump flow | 8.6 gpm
32.6 lpm
|
| SCV flow | 6 gpm
22.7 lpm
|
| Power Take-off (PTO) |
| Front PTO | independent
|
| Clutch | hydraulic disc
|
| Engine RPM | 2583@3000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 40
|
| Battery volts | 12
|
| References |
 |
| F Series Diesel Front Mower published in 2025, by Kubota |
