Kubota F2690
| | 2014 - 2025 |
| F 90 Series | | Front-mount mower |
|
Series map:
F2690
F3990
25.5hp
39.0hp
| Production |
| Manufacturer | Kubota
|
| Front-mount mower |
| Mechanical |
| Drive | 4x2 2WD
|
| | 4x4 4WD
|
| Differential lock | standard
|
| Power steering |
| Wet disc brakes |
| Two-post foldable ROPS. |
| Photos |
| No photos of the Kubota F2690 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Power Take-off (PTO) |
| Front PTO | independent
|
| Clutch | hydraulic wet disc
|
| Front PTO Type | 2545
|
| Engine RPM | $20,315@2015@@@@60-inch 2WD
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 40
|
| Charging volts | 12
|
| Battery volts | 12
|
| References |
 |
| Diesel Front Mower F2690E/F2690/F3710 published in 2022, by Kubota |
