Lawn Tractors > Kubota > F2690

Kubota F2690



Kubota F2690 lawn tractor photo
2014 -
F90 Series
Front-mount mower
Series map:
F2690
F3990
25.5hp
39.0hp
Production
ManufacturerKubota
Front-mount mower
Variants
F2690E2WD
Kubota F2690 Engine
25.5HP Kubota 1124cc 3-cyl diesel
Fuel tank16.1 gal
60.9 L
Engine details ...
Kubota F2690 Transmission
hydrostatic
Transmission details ...
Mechanical
Drive4x2 2WD
 4x4 4WD
Differential lockstandard
Power steering
Wet disc brakes
Two-post foldable ROPS.
Photos
No photos of the Kubota F2690 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Front PTOindependent
Clutchhydraulic wet disc
Front RPM2545
Engine RPM$20,315@2015@@@@60-inch 2WD
Dimensions & Tires
Wheelbase51.2 inches
130 cm
Weight1594 to 1606 pounds
Front tire23x10.5-12
Rear tire16x6.5-8
Full dimensions and tires ...
Kubota F2690 attachments
60" front-mount mower deck
72" front-mount mower deck
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps40
Charging volts12
Battery volts12
