Kubota F3710
| Production |
| Manufacturer | Kubota
|
| Front-mount mower |
| Original price was $30,771 in 2025 |
| Mechanical |
| Drive | 4x4 4WD
|
| Final drives | mechanical front
|
| Power steering |
| Wet discs brakes |
| Two-post folding ROPS. |
| Photos |
| No photos of the Kubota F3710 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 16.1 gal
60.9 L
|
| Hydraulic system | 3.7 gal
14.0 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 3.7 gal
14.0 L
|
| Pump flow | 8.6 gpm
32.6 lpm
|
| SCV flow | 6 gpm
22.7 lpm
|
| Power Take-off (PTO) |
| Front PTO | independent
|
| Clutch | hydraulic disc
|
| Engine RPM | 2583@2500
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 60
|
| Battery volts | 12
|
| References |
 |
| Diesel Front Mower F2690E/F2690/F3710 published in 2022, by Kubota |
| Page information |
 |
| Copyright 2025 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on November 29, 2025 |
