Yamaha YT5700


Yamaha YT5700 lawn tractor photo
1990 - 1991
Series map:
YT3600
YT5700
YT6700
12.0hp
16.0hp
18.0hp
Production
ManufacturerYamaha
Original price was $3,595 in 1991
Yamaha YT5700 Engine
16HP Yamaha 573cc 2-cyl gasoline
Fuel tank2.5 gal
9.5 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Drum brakes
Open operator station
Photos
No photos of the Yamaha YT5700 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase46.1 inches
117 cm
Weight525 lbs
238 kg
Front tire15x6.00-6
Rear tire20x10.00-8
Full dimensions and tires ...
YT5700 Serial Numbers
Location:Right side of the tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemflywheel magneto
Charging amps7
Charging volts14.5
Battery volts12
References
YT5700 references literature
Service Manual YT5700P YT6700P (LIT-19616-00-34) published in 1990
