Yamaha YT5700 Engine


Yamaha YT5700 lawn tractor photo
1990 - 1991
Series:YT3600YT5700YT6700
Engine Detail
Yamaha
gasoline
2-cylinder
vertical-shaft
Displacement:573 cc
34.97 ci
Bore/Stroke:3.07x2.36 inches
78 x 60 mm
Power (gross):16 hp
11.9 kW
Compression:8.6:1
Starter:electric
Starter volts:12
Oil capacity:1.9 qts
1.8 L
Sparkplug:NGK BPR5HS
Sparkplug gap:0.026 inches
0.660 mm
