Cub Cadet 1210
1985 - 1989 Garden tractor
Series map:
1204
1210
1211
12.0hp
12.0hp
12.0hp
Production Manufacturer Cub Cadet (a part of MTD)
Garden tractor Built in Brownsville, Tennessee, USA
Variants 1204 gear-drive
1210 hydrostatic
1211 hydro with hydraulic lift
Mechanical Two-wheel drive Manual steering Mechanical disc brakes Open operator station.
Tractor hitch Rear Type 0 Opt Optional Type sleeve hitch Opt Optional
Power Take-off (PTO) Front PTO independent
Clutch electric
Front PTO Type pulley
1210 Serial Number Location Serial number plate on the left side of the tractor frame, above the footrest.
Electrical Ground negative
Charging system alternator
Charging amps 15
Battery volts 12
References Owners's Manual Tractors 1204 - 1210 - 1211 (772-3865) published in 1987 Owners's Manual Tractors 1210 - 1710 - 1711 - 1712 (772-3504) published in 1985 Home Tractors published in 1985, by Cub Cadet Garden Tractors published in 1987, by Cub Cadet Cub Cadet Garden Tractors published in 1988 Cub Cadet Garden Tractors published in 1989
Page information Copyright 2026 TractorData.com® Email me: Peter@TractorData.com TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. Peter Easterlund - owner/authorThis machine's data modified on March 27, 2026
©2000-2026 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Transmission details ...
Cub Cadet 1210 photos...
Full dimensions and tires ...
Attachment details ...
