John Deere D150


John Deere D150 lawn tractor photo
2011
D100 Series
Lawn tractor
Series map:
D140
D150
D155
22.0hp
22.0hp
24.0hp
Production
ManufacturerJohn Deere
Lawn tractor
Built in Greeneville, Tennessee, USA
Original price$2,299 (2011)
John Deere D150 Engine
22HP Briggs & Stratton 655cc 2-cyl gasoline
Fuel tank4 gal
15.1 L
 2.4 gal (California model)
9.1 L
Engine details ...
Mechanical
Two-wheel drive
Steeringmanual
Mechanical shoe on transaxle brakes
Open operator station. Adjustable 15-inch tall seat with 5.5-inches of travel in ten positions. Fender-mounted cup holder. Optional nylon sunshade canopy or snow enclosure. Optional 12-volt power outlet.
Power Take-off (PTO)
Mid PTOelectric independent
Dimensions & Tires
Wheelbase48.9 inches
124 cm
Weight525 lbs
238 kg
Front tire15x6.00-6
Rear tire20x10.00-8
Full dimensions and tires ...
John Deere D150 attachments
48" mid-mount mower deck
snowblower
blade
Attachment details ...
D150 Serial Numbers
Location:Serial number on rear of tractor, left side, under fender.
Electrical
Groundnegative
Charging systemalternator
Charging amps16
Battery volts12
Battery GroupU1
References
D150 references literature
Operator's Manual D100 Series (OMGX24147) published in 2011
