International Harvester TD-7C
|
|
| Production | |
| Manufacturer | International Harvester |
| Industrial Crawler tractor | |
| International Harvester TD-7C Engine | |
| International Harvester 3.4L 4-cyl diesel | |
| Fuel tank | 30 gal 113.6 L |
 Engine details ... | |
| International Harvester TD-7C Transmissions | |
| 4-speed shuttle | |
| 8-speed gear | |
| 3-speed full power shift | |
 Transmission details ... |
| International Harvester TD-7C Power | |
| Engine (gross) | 60 hp 44.7 kW |
| Engine (net) | 56 hp 41.8 kW |
| Mechanical | |
| Drive | crawler |
| Final drives | spur gear |
| Wet disc brakes | |
| Open operator station. ROPS available. Optional cab with heater. | |
| Dimensions & Tracks | |
| Weight | 13208 lbs 5991 kg |
| 12-inch tracks | |
 Full dimensions and tracks ... | |
| TD-7C Serial Numbers | |
| 1969 | 501 |
| 1970 | 509 |
| 1971 | 771 |
| 1972 | 1097 |
| 1973 | 1543 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 22 |
| Battery volts | 12 |
| Battery AH | 96 |
| References | |
 | |
| 100C/TD-7C Crawlers published in 1971, by International Harvester | |
| TD-7C Crawler published in 1970, by International Harvester |
