New Holland PowerStar 100
|
|
Series map:
PowerStar 90
PowerStar 100
PowerStar 110
84.5hp*
86.7hp*
96.7hp*
*Estimated engine power for comparison only.
| Production | |
| Manufacturer | New Holland (a part of CNH) |
| Utility tractor | |
| Variants | |
| Farmall 100C | similar CaseIH model |
| New Holland PowerStar 100 Engine | |
| FPT 3.6L 4-cyl diesel | |
| ROPS Fuel tank | 30.3 gal 114.7 L |
| Cab Fuel tank | 34.3 gal 129.8 L |
| ROPS Exhaust fluid (DEF) | 2.8 gal 10.6 L |
| Cab Exhaust fluid (DEF) | 3.4 gal 12.9 L |
 Engine details ... | |
| New Holland PowerStar 100 Transmissions | |
| 24-speed two-speed power shift | |
| 12-speed power shuttle | |
| 24-speed creeper | |
 Transmission details ... |
| New Holland PowerStar 100 Power | |
| Engine (max) | 99 hp 73.8 kW |
| PTO (claimed) | 78 hp 58.2 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | electro-hydraulic |
| Hydraulic wet disc brakes | |
| Two-post folding ROPS. Cab optional with air-conditioning. | |
| Photos | |
| No photos of the New Holland PowerStar 100 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Rear valves | 2 or 3 |
| ROPS Pump flow | 16.9 gpm 64.0 lpm |
| Cab Pump flow | 21.7 gpm 82.1 lpm |
| Steering flow | 9.7 gpm 36.7 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift (at 24"/610mm) | 4123 lbs 1870 kg |
| 6938 lbsOptOptional 3147 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Rear PTO Type | 540/1000 |
| Dimensions & Tires | |
| Wheelbase | 92.5 inches 234 cm |
| Weight | 8157 to 10240 pounds |
| Front tire | 12.4-24 |
| 2WD Rear tire | 18.4-30 |
 Full dimensions and tires ... | |
| New Holland PowerStar 100 attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 120 |
| Battery CCA | 800 |
| Battery volts | 12 |
| References | |
 | |
| Powerstar Series Tractors published in 2025, by New Holland |
