John Deere 1M 25
|
|
| Production | |
| Manufacturer | John Deere |
| Sub-Compact Utility tractor | |
| Built in Augusta, Georgia, USA | |
| John Deere 1M 25 Engine | |
| Yanmar 1.3L 3-cyl diesel | |
| Fuel tank | 5.75 gal 21.8 L |
 Engine details ... | |
| John Deere 1M 25 Power | |
| Engine (gross) | 23.2 hp 17.3 kW |
| PTO (claimed) | 17.8 hp 13.3 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | spur gear |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. Cab optional with available air-conditioning. | |
| Photos | |
| No photos of the John Deere 1M 25 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pump flow | 3.5 gpm 13.2 lpm |
| Total flow | 7 gpm 26.5 lpm |
| Steering flow | 3.5 gpm 13.2 lpm |
| Tractor hitch | |
| Rear Type | I (limited) |
| Control | postion control |
| Rear lift (at 24"/610mm) | 758 lbs 343 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Mid PTO | independent |
| Mid PTO Type | 2100 |
| Dimensions & Tires | |
| Wheelbase | 57.1 inches 145 cm |
| Weight | 1602 to 2019 pounds |
 Full dimensions and tires ... | |
| John Deere 1M 25 attachments | |
| 60" mid-mount mower deck | |
| snowblower | |
| blade | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery CCA | 500 |
| Battery volts | 12 |
| References | |
 | |
| 1 Series Sub-Compact Utility Tractors published in 2026, by John Deere |
