John Deere 1E 23



John Deere 1E 23 tractor photo
2027 -
1 Series
Sub-Compact Utility tractor
Series map:
1E 23
1M 25
21.5hp
23.2hp
Production
ManufacturerJohn Deere
Sub-Compact Utility tractor
Built in Augusta, Georgia, USA
John Deere 1E 23 Engine
Yanmar 1.0L 3-cyl diesel
Fuel tank5.75 gal
21.8 L
Engine details ...
John Deere 1E 23 Transmission
hydrostatic
Transmission details ...
John Deere 1E 23 Power
Engine (gross)21.5 hp
16.0 kW
PTO (claimed)16.2 hp
12.1 kW
Mechanical
Four-wheel drive
Final drivesspur gear
Power steering
Wet disc brakes
Two-post folding ROPS.
Photos
No photos of the John Deere 1E 23 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pump flow3.5 gpm
13.2 lpm
Total flow7 gpm
26.5 lpm
Steering flow3.5 gpm
13.2 lpm
Tractor hitch
Rear TypeI (limited)
Rear lift (at 24"/610mm)758 lbs
343 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Mid PTOindependent
Mid PTO Type2100
Dimensions & Tires
Wheelbase57.1 inches
145 cm
Weight1475 lbs
669 kg
Full dimensions and tires ...
John Deere 1E 23 attachments
60" mid-mount mower deck
snowblower
blade
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Battery CCA500
Battery volts12
References
1E 23 references literature
1 Series Sub-Compact Utility Tractors published in 2026, by John Deere
